CBF150RE

LED Dual-lens Headlight

The angular and three-dimensional headlight group design
With an illumination width range of 15 meters, providing greater peace of mind during night rides

Three-dimensional LED Taillight

Visually unified with the headlights, offering maximum recognition
While also balancing lighting safety and the overall aesthetics of the vehicle

Sporty, Full Fuel Tank

Features smooth curves that outline a plump silhouette, with continuous and flowing lines
Conforming to the riding posture, fully displaying a grand and neat appearance

High-gloss Chrome-plated Exhaust

he surface is smooth and delicate, with lines that are flowing and minimalist
Enhance visual texture and endow the entire vehicle with a premium aura
Aviation-style Fuel Cap

Adopting aviation aesthetic design, it features smooth push-to-open operation
Exquisitely crafted in every detail, it presents a simple and sophisticated quality style
Sharp Wing-shaped Ornaments & Stripes

The highly dynamic wing-shaped design amplifies a sporty aura
Exquisitely crafted delicate marks elevate the overall premium visual appeal of the entire vehicle
PGM-FI Fuel Injection System

More fuel-efficient, more powerful
Faster startup, cleaner emissions
ABS Dual-channel ABS

Independent control of front and rear wheels
Preventing skidding and loss of control
Slipper Clutch

Smooth and seamless gear shifting without jerking
Delivering a lighter operating feel

Thoughtful Design, Ultimate Comfort

735mm Widened Front Bumper

High-strength stainless steel pipe + full-weld reinforced structure
Fully protect the engine and vehicle body to reduce damage from crashes
Thoughtful Design, Ultimate Comfort

Side-tipping Carrier

Thickened electroplating layer, rust and corrosion resistant, fearless of wind and rain
It can carry items daily, protect the vehicle body when it tips over, and is worry-free and durable
Thoughtful Design, Ultimate Comfort

Flat Tube Rear Carrier

Sleek and straight tubular structure design with stable load-bearing capacity
With even force distribution, more reliable for carrying cargo
Thoughtful Design, Ultimate Comfort

Comfortable Riding Triangle

757mm seat height
Three-point support fits your body’s curves, without getting tired after long-time riding/div>
Thoughtful Design, Ultimate Comfort

16.5L Large Fuel Tank

Over 800km ultra-long range to eliminate range anxiety
Ideal for daily commuting and long-distance riding
Thoughtful Design, Ultimate Comfort

VA High-Definition LCD Speedometer Assy

Clear visibility under strong light and soft glow without glare at night
All driving data at a glance, full control over vehicle status
Thoughtful Design, Ultimate Comfort

Hazard Warning Light

Safeguard every departure and stop
Thoughtful Design, Ultimate Comfort

20W Type A+C Dual-port Charging

No more battery anxiety on every trip

CBF150RE Configuration

Model and price
CBF150RE
Dual ABS Version / Optional Rollover, Racks

MSRP

/￥
CBF150RE
Dual Disc Brake Version / Optional Rollover, Racks

MSRP

/￥

Colors
PEARL RESEDA GREEN

CANDY SCINTILLATE RED

PEARL PROCYON BLACK
PEARL RESEDA GREEN

CANDY SCINTILLATE RED

PEARL PROCYON BLACK

Frame Parameters

Length(mm) 2058 2060
Width(mm) 781 778
Height(mm) 1076 1074
Seat Height(mm) 757 757
Curb Weight(kg) 137/146 135/144
Fuel Tank Capacity(L) 16.5 16.5
Maximum Speed(km/h) 96 96
Official Average Fuel Consumption(L/100km) 2.09 2.09
Wheelbase(mm) 1303 1303
Minimum Ground Clearance(mm) 181 181
Front Tire 80/100-18 80/100-18
Rear Tire 90/90-18 90/90-18
Brake FR DISC/RR DISK FR DISC/RR DISK

Engine Parameters

Engine Type Single-cylinder, 4-stroke, air-cooled Single-cylinder, 4-stroke, air-cooled
Maximum Power(kW/rpm) 8.8/7500 8.8/7500
Maximum Torque(N·m/rpm) 12.5/5500 12.5/5500
Displacement(cc) 149.16 149.16
Engine Cylinder Single-cylinder Single-cylinder
Bore x Stroke(mm) 57.300×57.842 57.300×57.842
Type of Cooling Air-cooled Air-cooled
Compression Ratio 9.5:1 9.5:1
Starting Method Electric Electric
